Device features:
The manual fire alarm button test device is designed and produced in accordance with the EN 54–11 annex and includes both operational and non–operational functional testing equipment. The front and rear positions are easily adjusted by the handwheel, which is suitable for various types of hand-to-hand newspapers:
GB 19880 Manual Fire Alarm ButtonBSEN 54-11 Fire detection and fire alarm systems. Manual call points
The Manual Call point test device included operation test device and non-operation test device as specified in EN 54-11and ISO standards. The operation test device consist of brass spherical ball, and adjustable suspending arm, mounting board and release fixture. The non-operation test device consist of lever, and adjustable suspending pivot, mounting board and weight.It’s used to test the operation performance of Manual call points (MCP) for fire detection and fire alarm systems.
Equipment Parameters :
Model: ZNEN54-11
Standards: EN54-11, GB 19880
Machine size: 800 mm long, 600mm wide, 1500mm high
Copper bead weight: 85 (+/–1) g
